Chi tiết sản phẩm
Nguồn gốc: Trung Quốc
Hàng hiệu: E-link
Số mô hình: LDP14-601S01-T/r
Tài liệu: E-link LNK-1240KVM 1080P HD....0.doc
Điều khoản thanh toán và vận chuyển
Số lượng đặt hàng tối thiểu: 1 PC
Giá bán: Có thể đàm phán
chi tiết đóng gói: Bao bì carton
Thời gian giao hàng: 3-12 ngày làm việc
Điều khoản thanh toán: L/C, T/T, Liên minh phương Tây, Moneygram, PayPal
Khả năng cung cấp: 1000 PC/tháng
Operating Temperature: |
-32° to +122° F. (-0° to +50° C) |
Storage Temperature: |
-40° to +185° F. (-40° to +85° C) |
Operating Humidity: |
5% to 80% (non-condensing) |
Storage Humidity: |
5% to 95% (non-condensing) |
Net Weight: |
200 g |
Dimensions (L x W x H): |
89mm x 104 mm x 28.3 mm |
Operating Temperature: |
-32° to +122° F. (-0° to +50° C) |
Storage Temperature: |
-40° to +185° F. (-40° to +85° C) |
Operating Humidity: |
5% to 80% (non-condensing) |
Storage Humidity: |
5% to 95% (non-condensing) |
Net Weight: |
200 g |
Dimensions (L x W x H): |
89mm x 104 mm x 28.3 mm |
Advantages
► Real Time Transmission, HDCP 1.2 compliant
► Supports DVI 1.0 and HDMI v1.3
► Supports resolutions up to1920*1080/60P
► Supports 1920*1080/60P resolution with color depth up to 24 bits/pixel
► Supports HDMI bit-rates up to 2.25Gbps color, 6.75Gbps total, CEC are NOT supported!
► Support 3D TV & EDID pass-through
► Support USB Keyboard and USB Mouse
► LPCM 7.1, Dolby® TrueHD, and DTS-HD Master Audio™
► Built-in EQ(Receiver), Plug and Play, Surface-mountable
► Up to 300m distance by OM3-300(Custom Available)
► Low RFI / EMI profile for sensitive applications
Overview
The LNK-1240KVM series is a high performance 1080P HDMI KVM Fiber Optic Extender that transmits high resolution DVI / HDMI signals over extreme distances using 2 cores fiber. This extender supports HDMI v1.3 signals with resolutions up to 1080P (1920x1080/60p) over cable distances up to 300m (Multimode Fiber) or 10km (Single Mode Fiber).
Technical Indexes
|
Performance |
|
|
Compliance |
HDMI v1.3 |
|
Maximum Pixel Clock Frequency |
225 MHz |
|
Maximum Video Bit Rate |
2.25 Gbps |
|
Supported Color Depth |
24-bit |
|
Supported Resolutions |
1920x1080/60P |
|
Digital Audio Support |
7.1 channel LPCM, 192 kHz, 24-bit audio capability |
|
Connections |
Description |
|
HDMI Input / Output |
1x HDMI Type-A Female connector |
|
Optical |
1x SFP+ port |
|
|
|
|
Fiber Cable Type / Max. Length |
50/125μ OM3-300 Multi-Mode Fiber: ≤ 1,000 ft. (≤ 300 meters) 9/125μ Single Mode Fiber: ≤ 10KM |
Ordering Information
|
Model |
Description |
|
LNK-1240KVM -T |
1080P HDMI KVM Fiber Optic Extender Transmitter |
|
LNK-1240KVM -R |
1080P HDMI KVM Fiber Optic Extender Receiver |
