Chi tiết sản phẩm
Place of Origin: China
Hàng hiệu: E-link
Chứng nhận: ISO9001, CE, FCC, RoHS
Model Number: LNK-FMSFP-2100
Tài liệu: E-link LNK-FSB-6 Series 6 P....0.pdf
Điều khoản thanh toán và vận chuyển
Minimum Order Quantity: 1pcs
Giá bán: Có thể đàm phán
Packaging Details: Industrial PoE Switch Standard Carton Packaging
Delivery Time: 7-10 working days
Payment Terms: L/C,T/T,Western Union,MoneyGram,PayPal
Supply Ability: 100000PCS/Month
adapters: |
Max. 6pcs |
entry/exit ports: |
12pcs pigtail |
Mounting options: |
Desktop |
Casing: |
Metal Case |
Weight: |
0.65Kg |
Dimensions (W x D x H): |
80 x 25 x 120 mm |
Operation Temperature: |
0°C to 50°C (32°F to 122°F) |
MTBF: |
> 200,000 hrs |
Relative Humidity: |
5% to 95% non-condensing |
adapters: |
Max. 6pcs |
entry/exit ports: |
12pcs pigtail |
Mounting options: |
Desktop |
Casing: |
Metal Case |
Weight: |
0.65Kg |
Dimensions (W x D x H): |
80 x 25 x 120 mm |
Operation Temperature: |
0°C to 50°C (32°F to 122°F) |
MTBF: |
> 200,000 hrs |
Relative Humidity: |
5% to 95% non-condensing |
Product Advantages
► 2x1.25G SFP ports to 1x2.5G SFP ports
► Support point-to-point topology function
► Can be used in CWDM system working as a wavelength converter for extending the system’s transmission capacity
► Must be used in couples
► Support hot-swap
Overview
LNK-FMSFP-2100 Series Gigabit Fiber Multiplexer aggregates 2 port Gigabit SFP into 1 port 2.5G SFP uplink, reducing the conversion CAPEX and increasing the fiber utilization effectively. The multiplexer can be used either in point-to-point topology functioning as a media converter for transporting two Gigabit Ethernet services over one fiber or in CWDM system working as a wavelength converter for extending the system’s transmission capacity doubly.
Technical Indexes
|
Optical Fiber |
|
|
Standards |
IEEE802.3ab 1000Base-T |
|
IEEE802.3z 1000Base-SX/LX/LH |
|
|
Interface Type |
1000Base-SX/LX/LH |
|
Optical Connector |
SC/PC,LC/PC |
|
Transmission distance |
220m~120Km (Depending on SFP Module) |
|
Multi-mode Fiber |
50/125 or 62.5/125µm |
|
Single-mode Fiber |
9/125µm |
|
Optical Port |
2 x 1.25G SFP + 1 x 2.5G SFP |
|
Date Transfer Rate |
|
|
SFP1 and SFP2 |
1.25Gbps |
|
SFP3 |
2.5Gbps |
|
Frame Loss Rate |
0% (64 ~1518 bytes @ 100% data rate) |
|
Frame rate |
100% line rate |
|
Maximum Frame size |
up to 10000bytes |
|
Latency |
2500ns/pair (Connected by short jumper line) |
|
Power Requirement |
|
|
Power Consumption |
4W Max. |
|
Power Adaptor |
220V(110-245V)AC,50Hz |
|
Voltage |
+5VDC |
|
LED Indicators |
|
|
P3 LNK (Green Color) |
ON: 2.5G Uplink is on. Blinking: Data transmission is on |
|
P2 LNK (Green Color) |
ON: SFP2 connecting is on. Blinking: Data transmission is on |
|
P1 LNK (Green Color) |
ON: SFP1 connecting is on. Blinking: Data transmission is on |
|
PWR (Green Color) |
ON: Power supply is normal |
|
Network management function |
|
|
All the LED status |
Support |
|
Connection status of the 3 port |
Support |
|
DDM Function on SFP Module |
Support |
|
Mechanical |
|
|
Dimensions (W x D x H) |
80 x 25 x 120 mm |
|
Weight |
0.65Kg |
|
Casing |
Metal Case |
|
Mounting options |
Desktop |
|
Environmental |
|
|
Operation Temperature |
0°C to 50°C (32°F to 122°F) |
|
Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
|
Relative Humidity |
5% to 95% non-condensing |
|
MTBF |
> 200,000 hrs |
|
Regulatory Approvals |
|
|
ISO9001,CE, FCC, RoHS |
|
|
Model |
Description |
|
LNK-FMSFP-2100 |
Gigabit SFP Fiber Multiplexer: 2x1.25G SFP to 2.5G SFP, Built-in Power Supply |
|
SFP Options |
► SFP option. Please select your SFP on our SFP Options Page . |
|
► SFP module is to be purchased separately. |
|
|
Mounting Options |
► Desktop |
